Technical Specifications
General Information
| Brand | APC |
| Model | AP8702S-WW |
| Product Type | Power Cord Kit |
| Category | Server & NAS PDU Cable |
Electrical Specifications
| Maximum Current Draw | 10A per phase |
| Maximum Input Current | 10A per phase |
| Output Connector | IEC 320 C13 |
| Input Connector | IEC 320 C14 |
Cable Configuration
| Cable Length | 0.61 meters |
| Number of Power Cords | 6 |
| Connector Type | Locking C13–C14 |
Environmental Conditions
| Operating Temperature | 0°C to 70°C |
| Operating Humidity | 20% – 80% |
| Operating Elevation | 0 – 3000 meters |
| Storage Temperature | -25°C to 75°C |
| Storage Humidity | 20% – 80% |
| Storage Elevation | 0 – 15000 meters |
Compliance & Certification
| Regulatory Approvals | CCC, PSE, VDE |
| Environmental Compliance | RoHS, REACH |
Physical Information
| Dimensions (H × W × D) | 9.45 × 2.76 × 1.58 inches |
| Weight | 1.56 lbs |
Warranty
| Warranty | No Warranty |
