Technical Specifications
Specification Summary
| PCI Express | PCI Express 5.0 x16 |
| AI TOPS | 1406 |
| CUDA core | 8960 |
| Memory Bus | 256-bit |
| Type | GDDR7 |
| Size | 16GB |
| Resolution | Up to 4K 480Hz or 8K 165Hz with DSC |
| Core Clock | 2482 MHz |
| Memory Clock | 28 Gbps |
| • BladeLink Fans |
Interface
| DisplayPort | 3 × DisplayPort 2.1b with UHBR20 (Supports up to 4K 480Hz or 8K 165Hz with DSC) |
| HDMI | 1 × HDMI Connector (Supports 4K 120Hz HDR, 8K 60Hz HDR, and Variable Refresh Rate per HDMI 2.1b Spec) |
| HDCP | 2.3 |
Power Specifications
| Connectors | 1 × 12V-2x6 Power Input |
| Recommended PSU | 750W |
| Power Consumption | 300W (High power consumption — please check PSU manual before installation) |
Display Options
| Display Port | 3 x DisplayPort 2.1b with UHBR20 |
| HDMI | 1 x HDMI Connector |
| Multi Display | Quad Display Support |
Application Programming Interfaces
| API | Version |
| DirectX | Microsoft DirectX 12 Ultimate |
| OpenGL | 4.6 |
Physical Specifications
| Dimensions | 304.4 × 115.8 × 41.6 mm (12" × 4.6" × 1.6") |
| Slot Size | 2 Slots |
Warranty Information
| Warranty | 3-year standard warranty + 2-years will be extended after online registration by the customer within 28 days of Purchase |
