Technical Specifications
Specification Summary
| GPU | NVIDIA GeForce RTX 5070 |
| Architecture | NVIDIA Blackwell |
| CUDA Cores | 6144 |
| Video Memory Type | GDDR7 |
| Video Memory Size | 12GB |
Video Memory Specifications
| Core Clock | 2542 MHz |
| Memory Clock | 28 Gbps |
| Memory Bus | 256-bit |
| Maximum Resolution | Up to 4K @ 480Hz or 8K @ 165Hz (with DSC) |
Display & Interface
| DisplayPort | 3 x DisplayPort 2.1b (UHBR20) |
| HDMI | 1 x HDMI (HDMI 2.1b) |
| HDCP Support | 2.3 |
| Multi-Display Capability | Quad Display |
| Bus Interface | PCI Express 5.0 x16 |
Power Specifications
| Power Connector | 1 x 12V-2x6 PCIe Power Input |
| Recommended PSU | 750W |
| Power Consumption | 250W (High power consumption — please verify PSU compatibility before installation) |
Application Programming Interfaces
| DirectX® Support | Microsoft DirectX® 12 Ultimate |
| OpenGL® Support | 4.6 |
Cooling & Build Features
| Cooling Technology | IceStorm 3.0 Advanced Cooling |
| Vapor Chamber | 34% Larger Vapor Chamber for superior heat dissipation |
| Fan System | BladeLink Fans with FREEZE Fan Stop & Active Fan Control 2.0 |
| Dual BIOS | Switch between Performance & Silent modes |
| Frame Design | Reinforced Metal Mid-Frame |
| Lighting | SPECTRA 2.0 RGB Lighting with SPECTRA LINK Lighting Sync Port |
| Backplate | Metal Die-Cast Backplate |
| Utility Software | All-new FireStorm Utility |
| Accessory | Bundled GPU Support Bracket |
| Extra Feature | Powered by NVIDIA Blackwell Architecture and DLSS 4 |
Physical Specifications
| Slot Size | 3.5 Slot |
| Cooling System | IceStorm 3.0 |
| Supported OS | Windows® 11 / 10 (64-bit, April 2018 Update or Later) |
Warranty Information
| Warranty | 3-year standard warranty + 2-years will be extended after online registration by the customer within 28 days of Purchase |
