Technical Specifications
Specification Summary
| GPU | NVIDIA GeForce RTX 5060 Ti |
| Architecture | NVIDIA Blackwell |
| Video Memory Type | GDDR7 |
| Video Memory Size | 8GB |
| CUDA Cores | 4608 |
Video Memory Specifications
| Core Clock | 2572 MHz |
| Memory Clock | 28 Gbps |
| Memory Bus | 128-bit |
| Maximum Resolution | Up to 4K @ 480Hz or 8K @ 165Hz (with DSC) |
Display & Interface
| DisplayPort | 3 x DisplayPort 2.1b (UHBR20) |
| HDMI | 1 x HDMI (HDMI 2.1b) |
| HDCP Support | 2.3 |
| Multi Display Support | Quad Display |
| Bus Interface | PCI Express 5.0 x8 |
Power Specifications
| Power Connector | 1 x 16-pin PCI Express Power Input |
| Recommended PSU | 600W |
| Power Consumption | 180W (High power consumption — please verify PSU compatibility before installation) |
Application Programming Interfaces
| DirectX® Support | Microsoft DirectX® 12 Ultimate |
| OpenGL® Support | 4.6 |
Physical Specifications
| Dimensions | 220.5 x 120.25 x 41.6 mm |
| Slot Size | 2 Slot |
| Cooling System | IceStorm 2.0 with BladeLink Fans |
| Build Features | Metal Backplate, FREEZE Fan Stop, All-new FireStorm Utility |
| Supported OS | Windows® 11 / 10 (64-bit, Version 1809 November 2018 or Later) |
Warranty
| Duration | 3-year standard warranty + 2 years will be extended after online registration by the customer within 28 days of Purchase |
