Technical Specifications
Specification Summary
| GPU | NVIDIA GeForce RTX 5060 Ti |
| Architecture | NVIDIA Ada Lovelace (Next-Gen) |
| CUDA Cores | 4608 |
| AI Performance (TOPS) | 759 |
| Bus Interface | PCI Express 5.0 x8 |
| Engine Clock (Boost) | 2572 MHz |
Memory Specifications
| Video Memory | 16GB GDDR7 |
| Memory Bus | 128-bit |
| Memory Clock | 28 Gbps |
Display & Resolution
| Display Outputs | 3 × DisplayPort 2.1b (UHBR20), 1 × HDMI® 2.1b |
| Maximum DisplayPort Resolution | Up to 4K @ 480 Hz or 8K @ 165 Hz (with DSC) |
| Maximum HDMI® Resolution | Up to 4K @ 480 Hz HDR or 8K @ 120 Hz HDR (with DSC, Gaming VRR supported) |
| HDCP Support | 2.3 |
| Multi-Display Capability | Quad Display (Up to 4 Monitors) |
Power & Thermal Specifications
| Recommended Power Supply | 600 W |
| Power Consumption | 180 W |
| Power Connector | 1 × 8-pin PCI Express Power Input |
| Cooling System | IceStorm 2.0 Dual-Fan Cooling |
| Slot Size | 2 Slot |
| SLI Support | No |
API & Software Support
| DirectX® Support | Microsoft DirectX® 12 Ultimate |
| OpenGL® Support | 4.6 |
| Operating System Support | Windows® 11 / 10 (64-bit, Version 1809 November 2018 or Later) |
Physical Specifications
| Card Length | 220.5 mm |
| Width | 120.25 mm |
| Height | 41.6 mm |
| Dimensions (inches) | 8.7" × 4.7" × 1.6" |
| Slot Size | Dual Slot |
Warranty Information
| Warranty | 3-year standard warranty + 2 years will be extended after online registration by the customer within 28 days of Purchase |
