Technical Specifications
General Information
| Model | TP-Link Archer GE230 |
| Product Type | Gaming Wireless Router |
| Category | Network And Router |
| Sub-Category | Wireless Router |
| Color | Black |
Wireless Performance
| Wi-Fi Standard | Wi-Fi 7 (802.11be) |
| Wireless Bands | Dual Band (2.4 GHz / 5 GHz) |
| Data Rate | BE3600 |
| 5 GHz Speed | 2882 Mbps |
| 2.4 GHz Speed | 688 Mbps |
| Antennas | 4× External Antennas |
Wireless Technologies
| Multi-Link Operation | Supported |
| Modulation | 4K-QAM |
| Resource Units | Multi-RUs |
| Mesh Networking | EasyMesh Compatible |
Gaming Features
| Game Acceleration | QoS Game Application Acceleration |
| Gaming Port | Dedicated Gaming Port |
| Game Server Routing | GPN Server Acceleration |
| Gaming Dashboard | Game Panel with Network Status |
| Traffic Monitoring | Gaming Statistics Reports |
Ports & Connectivity
| WAN Port | 1× 2.5 Gbps |
| LAN Port (High-Speed) | 1× 2.5 Gbps |
| Standard LAN Ports | 3× 1 Gbps |
| USB Interface | 1× USB 3.0 |
USB Features
| Supported Formats | NTFS, exFAT, HFS+, FAT32 |
| FTP Server | Supported |
| Media Server | Supported |
| Samba Server | Supported |
Security & Software
| Wireless Encryption | WPA, WPA2, WPA3 |
| Enterprise Security | WPA/WPA2-Enterprise (802.1x) |
| Parental Controls | HomeShield |
| Smart Integration | Alexa, Google Assistant |
Hardware & Controls
| Buttons | Power, LED, WPS, Reset |
| Operating Modes | Router Mode, Access Point Mode |
| Power Input | 12 V ⎓ 2.5 A |
Warranty
| Manufacturer Warranty | 1 Year |
