Technical Specifications
General Information
| GPU Chipset | Intel Arc B580 |
| Architecture | Intel Xe-HPG |
| Xe-Cores | 20 |
| Ray Tracing Units | 20 |
| Intel XMX Engines | 160 |
| GPU Peak Tops (Int8) | 233 |
Memory Specifications
| Memory Size | 12GB |
| Memory Type | GDDR6 |
| Memory Bus | 192-bit |
| Memory Bandwidth | 456 GB/s |
Core Clock Speeds
| Boost Clock | 2740 MHz |
Display & Resolution
| Maximum Resolution | 7680 × 4320 @ 120Hz HDR with DSC |
| Display Outputs | 3 x DisplayPort, 1 x HDMI |
| Maximum Displays | Up to 4 |
| Supported Technologies | HDR, DSC (Display Stream Compression) |
Interface & API Support
| Interface | PCI Express 4.0 x8 |
| DirectX® Support | 12 Ultimate |
| OpenGL® Support | 4.6 |
Cooling & Design
| Cooling System | Triple-Fan Cooling |
| Cooling Technology | Advanced heat dissipation with fin arrays |
| Slot Requirement | 2.2 Slot |
| Lighting | Blue Breathing Light |
Power & Efficiency
| Recommended Power Supply | 650W |
| Power Consumption | 200W (Typical Board Power) |
Physical Specifications
| Color | Black |
| Dimensions | 315 x 117 x 44 mm |
| Weight | 954 g |
warranty information
| Warranty | 03 Years |
