Technical Specifications
General
| Model | RTX 5060 Ti EPIC-X RGB OC |
| Architecture | TBDBlackwell |
| CUDA® Cores | 4608 |
Clock & Memory
| Clock Speed | 2407 MHz |
| Boost Speed | 2692 MHz |
| Memory Speed (Gbps) | 28 |
| Memory Size | 16 GB GDDR7 |
| Memory Interface | 128-bit |
| Memory Bandwidth (GB/sec) | 448 |
Display & Output
| Outputs | 3× DP 2.1b, 1× HDMI 2.1b, 4 Displays |
| Max Resolution | 4K @480Hz, 8K @165Hz (DSC3) |
Power
| Recommended PSU | 600W |
| Power Input | 1x8-pin |
Compatibility
| Interface & OS | PCIe 5.0 x8, Windows 10/11 64-bit, Linux 64-bit |
| Motherboard | PCIe-compliant, 2-slot x8 width required |
Physical Specifications
| Card Size | 11.77" × 4.72" × 1.57" |
| Slot | 2-slot |
| Box Dimensions | 15.04" x 7.64" x 2.84" / 382x194x72mm |
Warranty Information
| Warranty | 3-Years |
