Technical Specifications
Storage
| Model | ON900 |
| NAND Flash | 3D TLC NAND |
| Capacity | 256GB |
| Sequential Read Speed | Up to 3,500 MB/s |
| Sequential Write Speed | Up to 3,000 MB/s |
| TBW (Total Bytes Written) | 142TB |
Ports
| Interface | NVMe PCIe Gen 3.0 ×4 |
| NVMe Version | NVMe 1.3 / 1.4 |
Others
| Function | TRIM, NCQ, and S.M.A.R.T |
| ECC | Support LDPC (Low-Density Parity Check) Error Correction |
| End-to-End Data Path Protection | Supported |
| Power Loss Protection | Firmware-Based |
Physical Specification
| Thermal Throttling | Supported |
| Form Factor | M.2 2280 |
| Dimension (L × W × H) | 80mm × 22mm × 3.5mm |
| Weight | Approx. 7g |
| Operating Temperature | 0°C ~ 70°C |
| Storage Temperature | -40°C ~ 85°C |
| Humidity | 5% ~ 95% (non-condensing) |
Technical Info
| Supported Systems | Windows 10, Windows 8.1, Windows 8, Windows 7 (SP1), Windows Vista (SP2), Windows XP, macOS X v10.7+, Linux v2.6+, Chrome OS |
| Application | Laptops, Desktops, Ultrabooks, and Mini PCs |
Shock & Vibration Resistance
| Shock Resistance | 1500G, duration 0.5ms, Half Sine Wave |
| Vibration Resistance | 10–2000Hz, 1.5mm, 20G, 1 Oct/min, 30min/axis (X, Y, Z) |
Warranty Information
| Warranty | 05 Years |
