Technical Specifications
Memory & Storage
| DRAM | 1024MB (DDR4 DRAM Cache) |
| Heat Sink Type | Aluminum Alloy Dedicated Heatsink |
| NAND Flash | 3D TLC NAND |
| Capacity | 1TB |
| Sequential Read Speed | Up to 7,500 MB/s |
| Sequential Write Speed | Up to 6,800 MB/s |
| TBW (Total Bytes Written) | 650TB |
| MTBF (Mean Time Between Failures) | 1,600,000 hours |
Ports & Interface
| Interface | NVMe PCIe Gen 4.0 ×4 |
| NVMe Version | NVMe 1.4 |
Other Features
| Function | TRIM, NCQ, and S.M.A.R.T |
| ECC Support | LDPC (Low-Density Parity Check) |
| Power Loss Protection | Firmware-Based |
| End-to-End Data Path Protection | Supported |
| Thermal Throttling | Supported |
Technical Info & Warranty
| Supported Systems | Windows 11, 10, 8.1, 8, 7, macOS X, Linux |
| Model | ON1000PRO |
| Application | Gaming PCs, Desktops, Laptops, Workstations |
| Shock Resistance | 1500G, duration 0.5ms, Half Sine Wave |
| Vibration Resistance | 10–2000Hz, 1.5mm, 20G, 1 Oct/min, 30min/axis (X, Y, Z) |
| Warranty | 05 Years Limited Warranty |
