Technical Specifications
Model Information
| Category | Details |
| Model Name | ON1000 |
| Form Factor | M.2 2282 |
| Interface | NVMe PCIe Gen 4.0 ×4 |
| Flash Type | 3D NAND Flash |
| Available Capacities | 256GB / 512GB / 1TB |
Performance
| Category | Details |
| Sequential Read Speed | Up to 5,200 MB/s |
| Sequential Write Speed | Up to 4,700 MB/s |
| TBW (Total Bytes Written | 256GB – 162TBW 512GB – 325TBW 1TB – 650TBW |
| MTBF (Mean Time Between Failures) | 1,600,000 hours |
| NVMe Version | NVMe 1.4 |
Reliability & Features
| Category | Details |
| Error Correction | LDPC (Low-Density Parity Check) ECC |
| TRIM / SMART Support | Yes |
| End-to-End Data Path Protection | Supported |
| Power Loss Protection | Firmware-Based |
| Thermal Throttling | Supported |
Physical Specification
| Category | Details |
| Dimension (L × W × H) | 80mm × 22mm × 2mm |
| Weight | Approx. 7g |
Environmental Conditions
| Category | Details |
| Operating Temperature | 0°C ~ 70°C |
| Storage Temperature | -40°C ~ 85°C |
| Humidity | 5% ~ 95% (non-condensing) |
Compatibility
| Category | Details |
| Supported OS | Windows 10/11, Linux, macOS |
| Application | Desktops, Laptops, Ultrabooks, and Gaming PCs |
Warranty Information
| Warranty | 3 Years Limited Warranty |
