Technical Specifications
Graphics Processing Unit
| GPU Architecture | NVIDIA Ampere Architecture |
| CUDA Cores | 6,144 |
| Tensor Cores | 192 (Third Generation) |
| RT Cores | 48 (Second Generation) |
| Single-Precision Performance (FP32) | 19.2 TFLOPS³ |
| RT Core Performance | 37.4 TFLOPS³ |
| Tensor Performance | 153.4 TFLOPS⁴ |
Video Memory Specifications
| Memory Type | GDDR6 with ECC |
| Memory Size | 16 GB |
| Memory Interface | 256-bit |
| Memory Bandwidth | 448 GB/s |
Power & Thermal
| Total Board Power | 140W |
| Cooling Solution | Active (Single-Slot Blower) |
| System Interface | PCI Express® 4.0 ×16 |
| Power Connector | 1 × 6-pin PCIe |
Physical Specifications
| Form Factor | Single Slot — 4.4″ H × 9.5″ L |
Application Programming Interfaces
| Compute APIs | CUDA, DirectCompute, OpenCL |
| Graphics APIs | DirectX 12.0, Shader Model 5.1, OpenGL 4.6, Vulkan 1.2 |
Warranty Information
| Warranty | 2 Years |
