Technical Specifications
Key Features
| Capacity | 512GB |
| Form Factor | M.2 2280 |
| Flash Type | 3D TLC |
| Interface | PCIe Gen3x4 |
| Sequential Read Speed | Up to 3,500 MB/s |
| Sequential Write Speed | Up to 2,400 MB/s |
| MTBF (Mean Time Between Failures) | 1,500,000 hours |
Physical Specification
| Dimension (L × W × H) | 80mm × 22mm × 2.25mm (3.15” × 0.87” × 0.09”) |
| Weight | 9g |
Temperature
| Operating Temperature | 0°C ~ 70°C (32°F ~ 158°F) |
| Storage Temperature | -40°C ~ 85°C (-40°F ~ 185°F) |
Shock & Vibration Resistance
| Shock Resistance | 1500G, duration 0.5ms, Half Sine Wave |
| Vibration Resistance | 10–2000Hz, 1.5mm, 20G, 1 Oct/min, 30min/axis (X, Y, Z) |
Warranty Information
| Warranty | 03 Years |
