Technical Specifications
General Information
| Brand | Kingston |
| Series | KC3000 |
| Model | KC3000 2TB |
| Type | NVMe M.2 Solid State Drive |
| Interface | PCIe 4.0 x4 (NVMe 1.4) |
| Form Factor | M.2 2280 |
| Capacity | 2TB |
| Color | Black |
Performance
| Sequential Read Speed (MB/s) | Up to 7,000 MB/s |
| Sequential Write Speed (MB/s) | Up to 7,000 MB/s |
| Random Read (4K IOPS) | Up to 1,000,000 IOPS (typical for KC3000 series) |
| Random Write (4K IOPS) | Up to 1,000,000 IOPS (typical for KC3000 series) |
| TBW (Total Bytes Written) | 1.6 PBW (1,600 TBW) |
| MTBF | 2,000,000 Hours |
Physical Specifications
| Dimensions | 80 mm × 22 mm × 2.21 mm (512GB–1TB models reference size) |
| Weight | 9.7 g |
| Form | Single-Sided PCB |
| Heatsink | Graphene Aluminum Heat Spreader |
Environmental Conditions
| Operating Temperature | 0°C – 70°C |
| Storage Temperature | -40°C – 85°C |
| Vibration (Operating) | 2.17G peak (7–800Hz) |
| Vibration (Non-Operating) | 20G peak (20–1000Hz) |
Warranty Information
| Warranty | 05 Years |
