Technical Specifications
General Information
| Brand | Kingston |
| Series | FURY Renegade |
| Model | FURY Renegade 1TB |
| Type | NVMe M.2 Solid State Drive |
| Interface | PCIe 4.0 x4 (NVMe 1.4) |
| Form Factor | M.2 2280 |
| DRAM Cache | Yes |
| NAND Flash Type | 3D TLC |
| Controller | Phison E18 |
| Color | Black |
Performance
| Sequential Read Speed (MB/s) | Up to 7300 MB/s |
| Sequential Write Speed (MB/s) | Up to 6000 MB/s |
| Random Read (4K IOPS) | Up to 900,000 IOPS |
| Random Write (4K IOPS) | Up to 1,000,000 IOPS |
| TBW (Total Bytes Written) | 1.0 PBW (1000 TBW) |
| MTBF | 2,000,000 Hours |
Power Consumption
| Idle Power | 50 mW |
| Average Power | 0.33 W |
| Max Read Power | 2.8 W |
| Max Write Power | 6.3 W |
Physical Specifications
| Dimension (Heat Spreader) | 80 mm × 22 mm × 2.21 mm |
| Dimension (Heatsink) | 80 mm × 23.67 mm × 10.5 mm |
| Weight (Heat Spreader) | 7 g |
| Weight (Heatsink) | 32.1 g |
| Available Variants | With or Without Heatsink |
Environmental Conditions
| Operating Temperature | 0°C – 70°C |
| Storage Temperature | -40°C – 85°C |
| Humidity | 5% – 95% (Non-Condensing) |
| Vibration (Operational) | 2.17G peak (7–800Hz) |
| Vibration (Non-Operational) | 20G peak (20–1000Hz) |
Reliability & Endurance
| TBW (Endurance Rating) | 1.0PBW (1000TBW) |
| Data Protection | End-to-End Data Path Protection |
| Thermal Management | Dynamic Smart Thermal Throttling |
| Error Correction | LDPC ECC & SMART Monitoring |
| Wear Leveling | Advanced Static & Dynamic Wear Leveling |
Certifications
| Compliance | CE, FCC, RoHS, BSMI, VCCI, RCM Certified |
Warranty Information
| Warranty | 05 Years |
