Technical Specifications
Video/Audio Input
| IP Camera Input | 8 Channel |
Display Output
| Interface | 1 HDMI, 1 VGA |
| HDMI Resolution | 3840×2160 / 2560×1440 / 1920×1080 |
| VGA Resolution | 1920×1080 / 1440×900 / 1280×1024 |
| Multi-Screen Display | 1/4/5/6/7/8/9 Split |
Recording & Decoding
| Compression Standard | H.265 / H.264 |
| Decoding Capacity | 1CH 4K 15fps / 8CH 5MP 25fps |
| Record Mode | Manual, Schedule, Motion Detection |
Playback & Backup
| Sync Playback | 1CH 4K / 2CH 1080P |
| Backup Mode | FAT32 USB / Network |
Network
| Interface | 1 RJ45 (10/100Mbps) |
| Protocol Support | TCP/IP, DHCP, UDP, SMTP, NTP, CloudSEE |
| Smart Phone | iOS and Android Support |
Storage
| SATA Interface | 1 SATA Port |
| Max Capacity | Up to 10TB |
General
| Power Supply | DC 12V |
| Power Consumption | ≤10W (Without HDD) |
| Dimensions | 260 x 47.5 x 225mm |
| Net Weight | ≤ 1.0kg (Without HDD) |
Warranty
| Service Warranty | 1 Year Manufacturing Warranty |
