Technical Specifications
CPU Specifications
| Total Cores | 10 |
| Performance-cores | 6 |
| Efficient-cores | 4 |
| Low Power Efficient-cores | 0 |
| Total Threads | 10 |
| Max Turbo Frequency | 4.9 GHz |
| Performance-core Max Turbo | 4.9 GHz |
| Efficient-core Max Turbo | 4.4 GHz |
| Performance-core Base Frequency | 3.3 GHz |
| Efficient-core Base Frequency | 2.7 GHz |
| Intel DL Boost (CPU) | Yes |
| AI Frameworks (CPU) | OpenVINO, WindowsML, DirectML, ONNX RT, WebNN |
Memory Specifications
| Max Memory Size | 256 GB |
| Memory Types | DDR5 up to 6400 MT/s |
| Max Memory Channels | 2 |
| ECC Memory Supported | No |
GPU Specifications
| GPU Name | Intel Graphics |
| Graphics Base Frequency | 300 MHz |
| Graphics Max Dynamic Frequency | 1.8 GHz |
| GPU Peak TOPS | 4 |
| Xe-cores | 2 |
| Graphics Output | eDP 1.4b, DP 2.1 UHBR20, HDMI 2.1 FRL |
| Max Resolution (HDMI) | 4096 x 2304 @ 60Hz (TMDS), 7680 x 4320 @ 60Hz (FRL) |
| Max Resolution (DP) | 7680 x 4320 @ 60Hz |
| Max Resolution (eDP) | 3840 x 2400 @ 120Hz |
NPU Specifications
| NPU Name | Intel AI Boost |
| NPU Peak TOPS | 13 |
| Sparsity Support | Yes |
| Windows Studio Effects | Yes |
| NPU AI Frameworks | OpenVINO, WindowsML, DirectML, ONNX RT, WebNN |
Expansion Options
| DMI Revision | 4 |
| Max DMI Lanes | 8 |
| Thunderbolt 4 | Yes |
| Scalability | 1S Only |
| PCI Express Revision | 5.0 and 4.0 |
Package Specifications
| Socket | FCLGA1851 |
| Thermal Specification | PCG 2022C |
| Max Operating Temperature | 105 °C |
| Package Size | 45 mm x 37.5 mm |
Warranty Information
| Warranty | 3 Years |
