Technical Specifications
Basic Information
| Interface | PCIe 3.0 x4 (NVMe 1.3 Protocol) |
| Form Factor | M.2 2280 |
| Available Capacities | 128GB / 256GB / 512GB / 1TB / 2TB |
| NAND Flash Type | 3D NAND Flash |
| Controller | PCIe Gen3 NVMe Controller (Model Dependent) |
| MTBF (Mean Time Between Failures) | > 1,000,000 Hours |
Physical
| Dimensions (L × W × H) | 80 × 22 × 2.4 mm (Single-Sided Design) |
| Weight | <10 g |
| Build Material | PCB with Heat-Spreader Optional |
| Connector Type | M-Key (PCIe Interface) |
| Form Factor Compatibility | M.2 2280 Slot (Desktop / Laptop / Motherboard) |
Environmental
| Operating Temperature | 0°C – 70°C |
| Storage Temperature | -40°C – 85°C |
| Vibration Resistance | 3.1 GRMS (2–500Hz) |
| Shock Resistance | 100G / 6 ms |
| Humidity | 5% – 95% (Non-Condensing) |
Certifications & Compliance
| Safety & Compliance | CE, FCC, RoHS, cTUVus, KCC, BSMI, VCCI, RCM |
Package Contents
| Included Items | M.2 NVMe SSD, User Manual / Warranty Information |
| Compatibility | Compatible with Windows 10 / 11, macOS X, and Linux (NVMe Supported Systems) |
Warranty Information
| Warranty | 5 years |
