Technical Specifications
Camera & Image Sensor
| Image Sensor | 1/2.7" Progressive Scan CMOS |
| Resolution | 1920 × 1080 (Full HD) |
| Shutter Speed | 1/3 s to 1/100,000 s |
| Day & Night | IR cut filter |
| Minimum Illumination | Color: 0.01 Lux @(F2.0, AGC ON), B/W: 0 Lux with IR |
Lens & Viewing Angle
| Lens Type | Fixed focal lens |
| Lens Mount | M12 |
| Focal Length | 2.8 mm, 4 mm |
| Aperture | F2.0 |
| Field of View | 2.8 mm: H 105°, V 58°, D 123° |
4 mm: H 81°, V 43°, D 97°
| Angle Adjustment | Pan: 0°–360°, Tilt: 0°–75°, Rotate: 0°–360° |
IR & Night Vision
| IR Illuminator | IR LEDs, Smart Supplement Light: IR |
| IR Distance | Up to 30 m |
| IR Wavelength | 850 nm |
Video & Image Processing
| Video Compression | H.265/H.264/H.264+/H.265+ (Main), H.265/H.264/MJPEG (Sub) |
| Video Bit Rate | 32 Kbps to 8 Mbps |
| Day/Night Mode | Auto, Schedule |
| Wide Dynamic Range (WDR) | Digital WDR |
| Noise Reduction | 3D DNR |
| Mirror | Yes |
| Privacy Masking | Yes |
Network & Protocols
| Protocol | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS |
| Simultaneous Live View | Up to 6 channels |
| User / Host | Up to 32 users (administrator, operator, user) |
| Client | iVMS-4200, Hik-Connect |
| Web Browser | IE 10+, Chrome 57+, Firefox 52+ |
| Network Interface | 1 × RJ45 10M/100M self-adaptive Ethernet port |
Environmental & Protection
| Operating Temperature | -30°C to 60°C (-22°F to 140°F) |
| Operating Humidity | 95% or less (non-condensing) |
| Water Protection | IP67 |
Power Supply
| Power Supply | 12 VDC ±25%, 0.4 A, max. 5 W |
| PoE | 802.3af, Class 3, 36–57 V, max. 6.5 W |
Physical Details
| Dimension | Ø110 mm × 93.2 mm (Ø4.3" × 3.7") |
| Weight | Approx. 320 g (0.7 lb.) |
Warranty
| Warranty | 1 Year |
