Technical Specifications
Display
| Screen Size | 23.8 inch |
| Active Area | 527.04 × 296.46 mm |
| Resolution | 1920 × 1080 |
| Backlight | E-LED |
| Pixel Pitch | 0.2745 × 0.2745 mm |
| Brightness | 250 cd/m² |
| Viewing Angle | 178° (H) / 178° (V) |
| Color Depth | 16.78 M |
| Contrast Ratio | 1000:1 |
| Response Time | 14 ms |
| Refresh Rate | Typ. 60 Hz, Max. 100 Hz |
| Haze | 25%, 3H |
| Color Gamut | 72% NTSC |
| Reliability | 7 × 16 H |
Interface
| Video Input | HDMI 1.4 × 1, VGA × 1 |
| Audio Output | Audio Out × 1 |
| Data Interface | None |
| Control Interface | None |
Power
| Power Supply | DC 12V, 2.0A |
| Power Consumption | ≤ 24 W |
| Standby Consumption | ≤ 0.5 W |
Environment
| Working Temperature | 0°C to 40°C |
| Working Humidity | 20%–90% RH |
| Storage Temperature | -20°C to 60°C |
| Storage Humidity | 10%–90% RH |
General
| Casing Material | Plastic |
| VESA | 75 × 75 mm |
| Bezel Width | 2.0 mm (top/left/right), 23.55 mm (bottom) |
Dimensions & Weight
| With Base | 539.7 × 399.9 × 164.72 mm |
| Without Base | 539.7 × 327.33 × 43.5 mm |
| Package Size | 611 × 405 × 118 mm |
| Net Weight | 2.32 ± 0.5 kg |
| Gross Weight | 3.74 ± 0.5 kg |
Warranty Information
| Warranty | 03 Years |
