Technical Specifications
Print Technology
| Print Method | Thermal Transfer / Direct Thermal |
| Print Speed | 5 IPS (127 mm/s) |
| Print Resolution | 203 dpi (8 dots/mm) |
| Sensor Technology | Twin-Sensor Technology |
Media Specifications
| Paper Width | 4.25" (108 mm) |
| Paper Length | Min. 0.16" (4 mm) / Max. 68" (1727 mm) |
| Label Roll Diameter | Max. 5" (127 mm) |
| Core Diameter | 1", 1.5", 3" (25.4, 38.1, 76.2 mm) |
| Media Thickness | 0.0024" – 0.01" (0.06 – 0.25 mm) |
Ribbon Specifications
| Ribbon Types | Wax, Wax/Resin, Resin |
| Ribbon Length | 981' (300 m) |
| Ribbon Width | 1.18" – 4.33" (30 – 110 mm) |
| Ribbon Roll Diameter | 2.67" (68 mm) |
Processing & Memory
| Processor | 32-Bit RISC CPU |
| Flash Memory | 8 MB (4 MB User Storage) |
| SDRAM | 16 MB |
Connectivity
| Interface | USB |
Barcode Support
| 1D Barcodes | Code 39, 93, 128, EAN-8/13, UPC-A/E, Interleaved 2-of-5, Codabar, Postnet, QR, others |
| 2D Barcodes | PDF417, Datamatrix, MaxiCode, QR Code, Micro PDF417, Aztec Code |
Font Support
| Resident Fonts | Bitmap: 6, 8, 10, 12, 14, 18, 24, 30, OCR A & B |
| Asian Fonts | Traditional Chinese, Simplified Chinese, Japanese, Korean (16x16, 24x24) |
| TTF Fonts | Bold, Italic, Underline, 0° / 90° / 180° / 270° Rotation |
Software Compatibility
| Label Design Software | GoLabel (EZPL) |
| Driver Support | Windows 2000 / XP / Vista / 7 / 8.1 / 10, Server 2003 / 2008, macOS, Linux |
| DLL Support | Windows CE, .NET, Windows Mobile, Android |
Physical Dimensions
| Dimensions (L x W x H) | 11.2" x 8.9" x 6.8" (285 x 226 x 171 mm) |
| Weight | 5.51 lbs (2.5 kg) excluding consumables |
| Color | Black |
Warranty
| Warranty Period | 1 Year |
