Technical Specifications
Model Information
| Item | Details |
| Brand | Gigabyte |
| Model | M28U (SuperSpeed IPS 160Hz Variant) |
| Panel Type | SS IPS (Super Speed IPS) |
| Display Type | Edge-Lit LED |
| Screen Size | 27 inch (diagonal) |
| Resolution | 3840 × 2160 (UHD / 4K) |
| Aspect Ratio | 16:9 |
| Refresh Rate | 160Hz |
| Response Time | 1ms (MPRT) |
| Brightness (Typical) | 400 cd/m² |
| Contrast Ratio | 1000:1 |
| Color Depth | 10-bit (1.07 Billion Colors) |
| Color Gamut | 95% DCI-P3 / 129% sRGB |
| Pixel Pitch | 0.16 × 0.16 mm |
| Viewing Angle (H/V) | 178° / 178° |
| Surface Type | Non-Glare Matte Finish |
| Backlight Type | Edge Type |
Display Features
| Feature | Specification |
| Panel Technology | SuperSpeed IPS |
| Resolution | 3840 × 2160 (UHD 4K) |
| Brightness | 400 nits (Typical) |
| Contrast Ratio | 1000:1 |
| Viewing Angle | 178°(H) / 178°(V) |
| Response Time | 1ms (MPRT) |
| Refresh Rate | 160Hz |
| HDR Support | VESA DisplayHDR 600 |
| Flicker-Free Technology | Yes |
| Color Coverage | 95% DCI-P3 / 129% sRGB |
| Display Area (H × V) | 596.16 × 335.34 mm |
| HBR3 (High Bit Rate 3) | Supported |
Gaming & Visual Enhancements
| Feature | Description |
| OSD Sidekick | Control monitor settings via PC (HDMI/DP required) |
| Aim Stabilizer Sync | Minimizes motion blur while using Adaptive-Sync |
| Black Equalizer | Improves clarity in dark scenes |
| Dashboard Overlay | Displays system info such as FPS or temps |
| Crosshair Overlay | Custom aim reticle for FPS games |
| Timer / Counter / Refresh Display | On-screen game utilities |
| PiP / PbP Support | Dual-source multi-window display |
| KVM Function | Control multiple systems with one keyboard & mouse |
| Smart OD | Adaptive overdrive for motion optimization |
| HDMI-CEC | Syncs control with connected consoles (PS5/XSX) |
| 6-Axis Color Control | Advanced RGB & CMY adjustment |
| Apply Picture Mode / Auto-Update | Auto firmware and color optimization via GCC |
Connectivity
| Port Type | Quantity and Description |
| HDMI 2.1 | 2, Supports 4K @ 144Hz (DSC enabled) or 4K @ 144Hz (4:2:0) |
| DisplayPort 1.4 (DSC) | 1, Supports 4K @ 160Hz |
| USB Type-C | 1 , DP Alt Mode + Power Delivery (up to 18W) |
| USB 3.2 Gen 1 Downstream | 3, For peripherals |
| USB 3.2 Gen 1 Upstream | 1, For data/KVM |
| Audio Jack | 1, 3.5mm headphone output |
Audio
| Specification | Details |
| Built-in Speakers | Yes (3W × 2 stereo) |
| Audio Out | Yes (3.5mm jack) |
Power
| Specification | Details |
| Power Type | Internal Power Board |
| Power Consumption (Typical) | 27.6W *** |
| Power Saving Mode | 0.5W |
| Power Off Mode | 0.3W |
| Voltage Range | AC 100–240V, 50/60Hz |
| Note | ***CEC-standard test conditions |
Mechanical Design
| Feature | Range |
| Tilt Adjustment | -5° ~ +20° |
| Swivel Range | N/A |
| Pivot Rotation | N/A |
| Height Adjustment | 130 mm |
| VESA Wall Mount | 100 × 100 mm |
| Kensington Lock | Yes |
Physical Specification
| Specification | Details |
| Dimensions (W × H × D) with Stand | 615.67 × 517.65 × 193.63 mm |
| Dimensions (W × H × D) without Stand | 615.67 × 371.15 × 60.3 mm |
| Box Dimensions (W × H × D) | 939 × 490 × 167 mm |
| Net Weight (with Stand) | 6.48 kg |
| Net Weight (without Stand) | 4.56 kg |
| Gross Weight | 9.9 kg |
Included Accessories
| Item | Description |
| Power Cable | AC power cord |
| HDMI Cable | Included |
| DisplayPort Cable | Included |
| USB Cable | For KVM / data |
| Quick Start Guide | Yes |
Warranty Information
| Duration | 3 Years |
