DeepCool CH260 WH M-ATX Gaming Casing

Product Description

Powerful DeepCool CH260 WH M-ATX Gaming Casing for Clean Builds

Struggling to find a compact case that handles modern hardware without compromise? The DeepCool CH260 WH M-ATX Gaming Casing solves that problem directly. Built for Micro-ATX and Mini-ITX builds, it balances space efficiency with performance-focused compatibility, making it a practical choice for both gaming PCs and productivity systems. With a refined layout, solid materials, and well-planned internal clearances, the DeepCool CH260 WH M-ATX Gaming Casing is positioned as a strong option for builders who care about airflow management, up-to-date front I/O connectivity, and long-term upgrade flexibility — keeping your build minimal, clean, and future-ready. If you're serious about computer components that work together without bottlenecking your setup, this chassis deserves attention.

DeepCool CH260 WH M-ATX Gaming Casing Design Overview

The CH260 WH delivers a compact footprint while keeping internal space practical for modern builds and essential PC components like CPU, GPU, RAM, and others.

Build Materials and Form Factor

Measuring 438 × 225 × 312.5 mm and weighing 5.3 kg, it fits neatly into desk-focused setups where space efficiency is a priority. Its build combines ABS, SPCC steel, and a tempered glass side panel to improve rigidity and durability while offering a clean view of installed hardware. The tempered glass also supports a premium, tidy look — especially when paired with a well-planned airflow setup and the right Desktop Casing.

For compatibility, the chassis supports both Mini-ITX and Micro-ATX motherboards, including Micro-ATX rear-connector designs, making it flexible across a wide range of system layouts.

DeepCool CH260 WH M-ATX Gaming Casing Specifications and Performance Overview

The CH260 WH is designed with a performance-first layout that emphasizes compatibility and customization over pre-installed components.

Core Specifications at a Glance

• Product Dimensions: 438 × 225 × 312.5 mm
• Net Weight: 5.3 kg
• Materials: ABS + SPCC + Tempered Glass
• Motherboard Support: Mini-ITX, Micro-ATX, Micro-ATX (Rear Connector)
• Expansion Slots: 4
• Drive Bays: 1 × 3.5-inch, 1 × 2.5-inch
• Power Supply Type: ATX PS2 (maximum length 150 mm)

The absence of pre-installed fans allows users to select cooling solutions that best match their performance goals, noise preferences, and airflow strategy. Among Deepcool Casing options in this price range, that freedom is genuinely useful.

Cooling and Airflow Support in DeepCool CH260 WH M-ATX Gaming Casing

Cooling flexibility is a core advantage here, especially when paired with a well-matched CPU cooler that supports stable thermal performance.

Fan and Radiator Configuration

The chassis supports multiple fan and radiator configurations, making it suitable for both air-cooled and liquid-cooled system designs.

Supported fan placements:

• Front: 2 × 120 mm
• Top: 3 × 120 mm or 2 × 140 mm
• Rear: 1 × 120 mm

Radiator support focused on efficient heat exhaust:

• Top Radiator Support: 120 mm, 240 mm, or 360 mm
• Rear Radiator Support: 120 mm

There is no front or bottom radiator support, which reinforces a top-mounted cooling strategy ideal for CPU-focused thermal management. This design allows builders to optimize airflow paths based on component heat output. If you've been looking at the DeepCool CH270 Digital M-ATX Mini-Tower Gaming Casing (Black) as an alternative, the CH260 WH offers a cleaner white aesthetic with similar thermal versatility.

Key Features and Benefits of DeepCool CH260 WH M-ATX Gaming Casing

The CH260 WH is designed for functional performance rather than unnecessary complexity.

What Makes It Stand Out

• Flexible fan and radiator mounting options
• Support for large graphics cards and tall CPU coolers
• Modern front I/O including USB Gen2 Type-C
• Compact external size with efficient internal space usage
• Tempered glass panel for component visibility

These features make it suitable for users who want control over system thermals and layout without moving to a larger chassis.

Hardware Clearance and Compatibility

Despite its compact design, the CH260 WH provides generous clearance for high-performance components.

• Maximum CPU Cooler Height: 174 mm
• Maximum GPU Length: 388 mm, or up to 413 mm without front fans
• Maximum PSU Length: 150 mm

This allows compatibility with modern, full-length graphics cards, large tower-style CPU air coolers, and standard ATX power supplies within the specified limits. The layout supports clean component installation without compromising airflow.

Front I/O Connectivity and User Access

The front I/O panel is designed to meet modern connectivity needs without clutter.

Port Layout

• USB 3.0 × 2
• USB Gen2 Type-C × 1
• Audio/Mic Combo × 1

The inclusion of a USB Gen2 Type-C port ensures compatibility with newer peripherals and faster data transfer. This makes the case suitable for current and future system requirements — a detail that matters more than builders often realize at the time of purchase.

Storage, Expansion, and Power Supply Support

The storage layout is streamlined for modern builds that rely heavily on motherboard-based storage.

Drive Bay and Expansion Details

Supported drive bays include 1 × 3.5-inch and 1 × 2.5-inch configurations. This works well for systems using NVMe SSDs as primary storage while retaining space for additional SATA drives. The four expansion slots support standard GPU installations and additional expansion cards compatible with Micro-ATX systems.

The case supports ATX PS2 power supplies with a maximum length of 150 mm. This limitation helps maintain internal airflow efficiency and ensures better cable management within the compact chassis. The internal layout is designed for straightforward assembly, reducing build complexity while allowing efficient routing of cables and cooling components.

Build Quality, Long-Term Reliability, and Ideal Use Cases

The combination of ABS, SPCC steel, and tempered glass provides resistance to structural stress and everyday wear. The minimalist internal design reduces potential failure points, making the casing suitable for users who plan to upgrade components over time or maintain a stable system configuration for extended periods.

Who Should Buy the DeepCool CH260 WH

This casing is well-suited for:

• Micro-ATX gaming systems with high-performance GPUs
• Compact workstation builds using liquid or air cooling
• Clean showcase builds with visible internal components
• Users who want airflow customization without pre-installed limitations

Its balanced design supports multiple performance goals without unnecessary trade-offs. Across all DEEPCOOL Products in this compact segment, the CH260 WH consistently delivers on both aesthetics and practical cooling freedom.

Where to Buy DeepCool CH260 WH at Best Price in BD?

If you are planning a Micro-ATX or Mini-ITX system that prioritizes compatibility, flexible cooling support, and modern front-panel connectivity, the DeepCool CH260 WH M-ATX Gaming Casing is a practical option to consider alongside essential PC components for balanced system planning. With support for large graphics cards, multiple cooling layouts, and an efficient internal structure, it fits both gaming-focused setups and professional workstations without unnecessary bulk. Designed to adapt to evolving hardware needs, this casing offers a balanced foundation for long-term builds. You can complete your online pc build with confidence by ordering directly through PCB Store BD, where we provide reliable after-sales service, warranty claims, and technical support across Bangladesh.
