Technical Specifications
General Information
| Product Category | Interactive Flat Panel |
| Product Sub-Category | Avocor Interactive Flat Panel |
| Brand | Avocor |
Processor & Performance
| CPU | A55 x 4 |
| Chipset | Amlogic T982 |
| GPU | Mali G52 MP2 |
Memory & Storage
| RAM | 8GB |
| ROM | 64GB |
Display Specifications
| Screen Size | 65 inch |
| Resolution | 3840 × 2160 @ 60Hz |
| Brightness | 350 cd/m² |
| Aspect Ratio | 16:9 |
| Contrast Ratio | 5000:1 |
| Response Time | 6.5 ms |
| Display Colors | 10-bit, 1.07 billion |
| Viewing Angle | 178° / 178° |
| Backlight | Direct-lit LED |
Touch & Surface
| Touch Points | Up to 40 + 1 stylus |
| Surface | 3.2mm zero-bonded anti-glare |
Audio & Microphone
| Built-in Speakers | 2 × 16W front-facing |
| Audio Input | 1 × 3.5mm |
| Audio Output | 3.5mm, Optical SPDIF |
Networking & Connectivity
| WiFi | WiFi 6 |
| Ethernet | 2 × RJ-45 LAN |
Ports & Interfaces
| HDMI Input | 2 × HDMI 4K@60Hz |
| HDMI Output | 1 × HDMI Out |
| USB Ports | USB-A 3.0, USB-B 2.0, Type-C |
| Control Ports | IR In, RS-232 |
| OPS Slot | Yes |
Power & Operation
| Power Supply | AC 100–240V, 50/60Hz |
| Power Consumption | <360W |
| Standby Power | 0.5W |
| Operation Time | 16 hours × 7 days |
Physical Specifications
| Dimensions | 1488.4 × 896.6 × 87.2 mm |
| Weight (Net) | 34.3 kg |
| Wall Mountable | Yes |
| Operating Temperature | 0–40°C |
Compatibility
| Supported OS | Windows, macOS, Linux |
In the Box
| Included Items | Remote, stylus, wall mount, cables |
Warranty
| Warranty | 3 Years |
