Technical Specifications
Processor & Chipset
| CPU Support | AMD Ryzen 9000 / 8000 / 7000 Series (Socket AM5), Chipset: X870 |
Memory & Storage
| Memory | 4× DDR5 DIMM, Dual Channel, ECC/Non-ECC, up to 8000+ MHz OC, 256GB Max |
| Storage | 3× M.2 (Gen5/Gen4/Gen3+SATA), 4× SATA3 (2 via ASM1061), RAID 0/1/10 |
Graphics & Audio
| Integrated GPU | AMD RDNA (CPU Dependent), HDMI 2.1 (4K@120Hz), USB4 Display (8K@30Hz) |
| Audio | Realtek ALC1220, 7.1 CH, Nahimic Audio, Impedance Sensing, Gold Jacks |
Networking & Wireless
| LAN & WiFi | 2.5G LAN (Dragon RTL8125BG), Wi-Fi 7 (802.11be), BT 5.4, MU-MIMO |
USB & Expansion
| USB Ports | 2× USB4, 7× USB 3.2 (Type-A/C), 9× USB 2.0; USB PD 3.0 Supported |
| Expansion Slots | 1× PCIe 5.0 x16, 1× PCIe 4.0 x16 (x4), M.2 Key-E, AMD CrossFire |
Form Factor & Features
| Size & Design | ATX (30.5 × 24.4 cm), 8-layer PCB, 14+2+1 Power Phases, Dr.MOS, Heatsink Armor |
Internal Connectors
| Headers | 2× CPU Fan, 4× Chassis Fan, AIO Pump, RGB, 3× ARGB, TPM, Thermistor, Audio, Power |
Rear I/O
| Ports | HDMI, 2× USB4-C, 4× USB 3.2, 6× USB 2.0, SPDIF, LAN, Audio Jacks, BIOS Flashback |
Special Features
| Highlights | PCIe Gen5, DDR5, USB4, BIOS Flashback, EZ Mode, Polychrome SYNC, Driver Auto Installer |
Software & UEFI
| Utilities | A-Tuning, Dragon LAN, Full HD UEFI, Instant Flash, ASRock App Shop |
Wireless Module
| Wi-Fi & BT | Wi-Fi 7 (2.4/5/6GHz), 2×2 MIMO, 160MHz Channel, Bluetooth 5.4 |
Warranty
| Duration | 3 Years Manufacturing Warranty |
